CUSTOMER SATISFACTION IS OUR BUSINESS RBT SERVICES, INC is committed to providing customer satisfaction. We value our customers and the product or service they provide. For this reason, we work with each customer to develop a product to fit their specific need. We take pride in helping our customer take care of their customer. A & R TRANSPORT AC & J RAILROAD AES BEAVER VALLEY COGENERATION AMERICAN COMMERCIAL TERMINALS AMERICAN ROCK SALT, LLC AMERICAN WAREHOUSING OF NEW YORK ANHEUSER BUSCH ANKER INDUSTRIES ARROW TERMINALS ASHLAND CHEMICAL CO. BADGER MINING BULKMATIC BULK TRANSPORT BULK TRANSIT CARBO CERAMICS CALIFORNIA PORTLAND CEMENT CARGOFLO CARMEUSE NORTH AMERICA CEMEX CHEMICAL LIME CHEVRON COMBINED TERMINALS CONRAIL FLEXIFLO TERMINALS EH LYNN INDUSTRIES E.I. DUPONT ENX ESSROC ITALCEMENTI GROUP FAIRMONT MINERALS FRANCIS DRILLING FLUIDS FREIGHT SERVICES, INC GENERAL MILLS GLOBAL MATERIALS GULF SULPHUR HALLIBURTON ENERGY HEIL OF LANCASTER HEIL OF TEXAS HEIL TRAILER INTERNATIONAL HEXION CHEMICAL HORNBROOK TRUCKING INFILTRATOR SYSTEMS ISG RESOURCES, INC K-A STEEL CHEMICALS KAW TRANSPORT KELLEHER CONSTRUCTION, INC KINDER MORGAN KINMAN SUPPLY L.G. EVERIST LAFARGE LEHIGH CEMENT LIBERTY PRESSURE PUMPING MATERIAL DELIVERY SERVICES MODERN TRANSPORTATION MONTGOMERY TANK LINES MORTON SALT NOBILE OIL SERVICE NORFALCO NORFOLK SOUTHERN PNEUMATIC DUST CONTROL PRAIRIE TRANSPORTATION RAIL SERVICES, INC RIVER BEND TRANSPORT S & T TRUCKING SAFE HANDLING SAFETY KLEEN SANTROL SAVAGE INDUSTRIES STEVEDORING SERVICES, of AMERICA TIDEWATER TRANSIT, INC TOTAL FOODS CORPORATION TRANSFLO TRANSWOOD, INC. UNION PACIFIC RAILROAD VENTURA TRANSFER VIRGINIA DEPARTMENT OF TRANSPORTATION WEDRON SILICA WISC WE'RE WORKING HARD TO MAKE YOUR JOB EASIER RBT Services is dedicated to providing the best possible service from building new conveying systems, providing rail accessories, to repairing or reconditioning existing equipment. We utilize up-to-date computer equipment and software along with an exceptional staff to develop solutions for the most challenging material handling requirements. With our broad based capabilities we can assure timely delivery of ruggedly constructed, quality equipment. We perform rigorous product testing, and visit sites during and after installation to help our clients solve problems with existing equipment, or upgrade to improve their operations. RBT is committed to maximum equipment performance and customer satisfaction.

FLY ASH

RBT Services, Inc was approached with a challenge to design and build a system to handle type "C" and type "F" flyash from railcar to truck at a rate of 60 TPH. The customers current type of conveyor had several problems. Problem: Premature wear of conveyor chain that is costly to replace. Solution: RBT Services, Inc designed a conveyor with a hardened steel chain, hardened steel sprockets and UHMW wear strips on the conveying flights, which are inexpensive to replace and provide excellent wear resistance.   Problem: Tracking tonnages. Solution: RBT Services incorporated a scale system using a modified impact scale that is used on stationary silos. This system has an accuracy of +/- 3%.   Problem: The need to open railcar gates mechanically. Solution: RBT Services, Inc designed a pneumatic gate opener onto the tail section of our conveyor that is capable of 2000 ft./lbs. of torque.   Problem: Excessive dust while loading to truck. Solution: RBT Services, Inc installed a 1200 CFM dust collector with automatic air purge filter cartridges, and engineered truck dome seal, which has virtually eliminated all dust emission.   Problem: The need to operate air lancing, and air vibrating equipment. Solution: RBT Services incorporated a 37 CFM 125 PSI piston air compressor for the air lancing of railcars and the operation of non-impact "quiet and light" vibrators. This feature made the unit self-contained and with no need for a secondary portable air compressor. RBT Services Inc, responded to these challenges with a completely self-contained portable conveyor with abrasion resistant steel on all wear surfaces and successfully achieved all of the customer's goals.

COCOA BEAN TRANSLOADING

Another example of RBT Services commitment to meet customers' needs is our specially designed conveyor built to load cocoa beans. Our customer needed to gently load cocoa beans from burlap sacks to railcar, open top trucks, and covered hopper trucks. RBT Services has designed two styles of conveyors to meet this challenge. First is our standard model 2450 with several modifications to allow the gentle handling of the high volume product the customer required. The second machine was a new design. We call it the cocoa bean II conveyor. This conveyor extends 40' inside a closed van trailer and splash loads cocoa beans at a rate of 100 TPH. This machine also elevates high enough to reach and load rail cars and pneumatic style trucks. Both machines are self-propelled, raise and lower hydraulically and have large debagging hoppers built on the unit to allow operators to slit and dump the burlap sacks. Both machines are of stainless steel construction with a white food grade belt. These units are available with either electric or diesel power.

BELT 18" & 24" BELT CONVEYORS W/ FOUR WHEEL STEERING 18" & 24" BELT CONVEYORS W/ TWO WHEEL STEERING 36" BELT CONVEYORS 42" BELT CONVEYORS 36" PADDLE BELT CONVEYOR NOSE OVER BELT CONVEYOR SALT CONVEYOR w/ CRUSHER Model 4255 CHAIN 18", 24" & 36" CHAIN CONVEYORS COCOA BEAN COCOA BEAN I COCOA BEAN II DRAG-A-FLIGHT MODEL 3625 DOUBLE SCREW CONVEYOR DOUBLE SCREW CONVEYOR OPTIONS ALUMINUM WALKWAY DRIVE OVER TAIL DUMP HOPPER GATE OPENER TAIL MAGNETS OPERATOR'S PLATFORM POWERED SOUT WINCH RAIN HOOD SCREENER SECURITY OPTIONS SPOUT OPTIONS

Custom Fabricatoin AMONG OUR MANY PRODUCTS AND SERVICES WE CAN ALSO PROVIDE CUSTOM FABRICATION TO FIT YOUR NEEDS. WE ARE CAPABLE OF PROVIDING THIS SERVICE AT A REASONABLE COST AND TIME PERIOD WITH COMPUTER AIDED DESIGN AND A SKILLED WORK FORCE. ALUMINUM HYDRAULIC TANK 10 CUBIC YARD BEDDING BOX GYPSUM HOPPER CUSTOM SILO

Gypsum Hopper FEATURES: HEAVY DUTY STEEL CONSTRUCTION 1/2” THICK UHMW HOPPER LINER REMOVABLE LEGS FOR SHIPMENT 2’-0” x 12’-0” DISCHARGE 14’-0” W x 24’-0” L x 21’-0” TALL OPTIONS: LARGER CAPACITIES CUSTOM DESIGNED FOR VARIOUS COMMODITIES

Custom Silo - 60 Ton Sand Capacity FEATURES: HEAVY DUTY STEEL CONSTRUCTION BIN INDICATOR CAGED LADDER FOR ROOF ACCESS 10” DIA. x 3’-0” DISCHARGE CHUTE 4” DIA. INLET w/ CAMLOCK FITTING 12’-0” WIDE x 12’-0” x 34’-3” TALL ONE MANUALLY OPERATED SLIDE GATE FOR EMERGENCY SHUT-OFF ONE AIR OPERATED OPERATED SLIDE GATE OPTIONS: LARGER CAPACITIES CUSTOM DESIGNED FOR VARIOUS COMMODITIES LIGHTING FOR NIGHT OPERATION WEATHER SKIRTING AIR COMPRESSORS

Case Study One Case Study Two

MODEL DC600 MODEL DC1400 MODEL DC2000x

Sales: Parts: Phone: 270-763-6649 Request More Information: Name:   Company:   E-Mail:   Phone:   Area of Interest:   Questions/Comments:

Steam to Hot Water Heater, Model HW400

MasterVAC - MODEL MV7012 MasterVAC - CONTINUOUS FLOW

MasterVAC - MODEL MV7012 Master Vac is a vacuum system with a gravity dump. The machine cycles between vacuum mode and dump mode a t a rate of 1000 to 1500 pounds per minute. Conveying products under a vacuum handles commodities very gently never exposing them to heat as in a push pull system. The system automatically cycles between vacuum and dump mode by using a load cell (adjustable for different commodities) that senses the weight in the receiver. Unit is constructed of 304 stainless steel, which is ideal for handling food grade products or materials that can not contact any foreign particles. FEATURES: CUMMINS 150HP DIESEL 7012 BLOWER - 1400CFM AT 15"HG SELF-PROPELLED AT 5MPH FULLY CLEANABLE STAINLESS STEEL HOPPER CAPACITY 30 - 40 TPH GREAT FOR FOOD GRADE AND SENSITIVE COMMODITIES ALL HYDRAULIC CONTROLS LIGHTING FOR NIGHT TIME OPERATIONS RENTAL UNITS AVAILABLE LOAD RAIL TO TRUCK / TRUCK TO RAIL OPTIONS: FALL PROTECTION ELECTRIC POWERED click here to view a schematic drawing

MasterVAC - CONTINUOUS FLOW Master Vac is a vacuum system with a gravity dump. The machine cycles between vacuum mode and dump mode a t a rate of 1000 to 1500 pounds per minute. Conveying products under a vacuum handles commodities very gently never exposing them to heat as in a push pull system. The system automatically cycles between vacuum and dump mode by using a load cell (adjustable for different commodities) that senses the weight in the receiver. Unit is constructed of 304 stainless steel, which is ideal for handling food grade products or materials that can not contact any foreign particles. FEATURES: CUMMINS 140HP SIX CYLINDER DIESEL ENGINE 7102 VACUUM PUMP RATED AT 1400CFM @ 15" Hg 14CFM @ 130 PSI COMPRESSED AIR SYSTEM (6) FILTER CARTRIDGES / 600 SQ. FT. CLOTH AREA (DIFFERENT FILTER MEDIAS AVAILABLE) MILD STEEL HYDRAULICALLY DRIVEN ROTARY VALVE SELF PROPELLED ALL HYDRAULICALLY CONTROLLED OPTIONS: 7108 VACUUM PUMP RATED AT 2100CFM @ 15" Hg STAINLESS STEEL ROATARY VALVE HYDRAULIC VIBRATORS AIR SLIDE ADAPTERS AUXILLIARY BLOWER FOR AIR SLIDE CARS THE CONTINUOUS FLOW MASTER VAC IS BUILT ON A 12,000 LB CHASSIS AND IS TOTALLY SELF-CONTAINED. THE MASTER VAC IS SELF-PROPELLED AT A MAXIMUM SPEED OF 4 MPH. THE FILTER RECEIVER IS RAISED ABOVE THE TRUCK OR RAILCAR VIA HYDRAULICS TO ALLOW TRANSFER TO BEGIN. THE CUMMINS DIESEL ENGINE PROVIDES 140 H.P. TO RUN THE VACUUM PUMP. THE VACUUM CONVEYS VARIOUS COMMODITIES TO THE FILTER RECEIVER AND THROUGH THE ROTARY VALVE INTO THE TRUCK OR RAILCAR. THE CONTINUOUS FLOW MASTER VAC CONVEYS MATERIAL AS THE FILTER CARTRIDGES ARE BEING CLEANED VIA A PULSAIR CLEANING SYSTEM. WITH THIS UNIQUE SYSTEM, THIS ALLOWS THE CONTINUOUS FLOW MASTER VAC TO HANDLE COMMODITIES WITH GREATER CAPACITY, LESS DISPLACED DUST AND A WIDER VARIETY OF DUSTY COMMODITIES, I.E. CEMENT, FLOUR AND FLYASH ALONG WITH MANY OTHERS. IF THE NEED ARISES TO UNLOAD PLASTICS OR OTHER COMMODITIES YOU DO NOT WANT TO RUN THROUGH A ROTARY VALVE, THEN A STANDARD MASTERVAC RECEIVER CAN BE INSTALLED BY REMOVING TWO PINS, AS ALWAYS WE WANT TO MAKE OUR MACHINES AS FLEXIBLE AS POSSIBLE, PLEASE GIVE US A CALL FOR ALL YOUR TRANSFER PROJECTS.

SAFETY SHOWERS - MODEL SS300 ZC FILTER W/ HINGED LID PORTABLE DOUBLE SCREW CONVEYOR NOSE OVER BELT CONVEYOR PORTABLE PADDLE BELT CONVEYOR

MODEL AP500 MODEL AV200 MODEL PP106 MODEL SP320

MODEL PE400 ETHANOL PUMPS OTHER PUMPS

BOOT SEAL MODEL 1324 BUMPER POST MODEL 1010 CAR PULLERS MODEL CP1590 MODEL CP2034 CROSS DOCK CROSS DOCK FILL TUBES FILL TUBES FIFTH WHEEL DUMP CHASSIS FIFTH WHEEL DUMP CHASSIS GATE OPENERS GATE OPENERS HOSE STORAGE RACK HOSE STORAGE RACK RAILCAR VIBRATORS ELECTRIC MODELS HYDRAULIC MODELS PNEUMATIC MODELS SAFETY SHOWERS MODEL SS10 MODEL SS125 MODEL SS300 TEMPERATURE PROBE TEMPERTURE PROBE TRACK PANS TRACK PANS TRUCK ACCESS PLATFORMS TRUCK ACCESS PLATFORMS

INGROUND PADDLE BELT CONVEYOR IRON ORE BARGE UNLOADING FACILITY ROOFING GRANULES UNLOADING FACILITY BAUXITE UNLOADING FACILITY CEMENT TRANSFER TERMINAL BULK STORAGE & DISTRIBUTION FACILITY SCREENING & BLENDING FACILITY

ZC FILTER ZCII FILTER ZC filter W/ Hinged Lid

MOBILE CONVEYORS - Models 1850 & 2450 FEATURES: ONE MAN OPERATION TWO WHEEL DRIVE W/ FOUR WHEEL STEERING HEAD DRIVE W/ 12" TAKEUP 5" THICK LOW PROFILE TAIL FULLY ENCLOSED TROUGH 440/220V 3 PHASE POWER DUST COLLECTOR W/ AUTOMATIC SHAKER FLEXIBLE LOADOUT SPOUT W/ HAND WINCH LOCALIZED LIGHTING FOR NIGHT TIME OPERATION WHITE FOOD GRADE BELT HEAVY DUTY BEARING STAINLESS STEEL SEALED BEARING IDLERS SHIPS LEGAL ON GOOSENECK TRAILER MODEL 1850 RATED @ 45 - 65 TONS PER HOUR MODEL 2450 RATED @ 75 - 100 TONE PER HOUR OPTIONS: FOUR WHEEL DRIVE LARGER DUST COLLECTORS (2000 CFM) STAINLESS STEEL DUST COLLECTOR DIESEL POWER (30 HP) HYDRAULIC VIBRATORS BELT SCALE W/ +/-1% ACCURACY 5 FT. EXTENSION TO REACH RAILCARS USES: LOADING / UNLOADING OF SMALL PARTICLES SUCH AS: SAND SODA ASH PEBBLE LIME ROOFING GRANULES SALT click here to view a schematic drawing

MOBILE CONVEYORS - Models 1850s & 2450s FEATURES: ONE MAN OPERATION TWO WHEEL DRIVE W/ TWO WHEEL STEERING HEAD DRIVE W/ 12" TAKEUP 5" THICK LOW PROFILE TAIL FULLY ENCLOSED TROUGH 440/220V 3 PHASE POWER DUST COLLECTOR W/ AUTOMATIC SHAKER FLEXIBLE LOADOUT SPOUT W/ HAND WINCH LOCALIZED LIGHTING FOR NIGHT TIME OPERATION WHITE FOOD GRADE BELT HEAVY DUTY BEARING STAINLESS STEEL SEALED BEARING IDLERS SHIPS LEGAL ON GOOSENECK TRAILER MODEL 1850 RATED @ 45 - 65 TONS PER HOUR MODEL 2450 RATED @ 75 - 100 TONE PER HOUR MODEL 1800 CHAIN STYLE FOR FINE MATERIALS IS ALSO AVAILABLE RATED AT 45-55 TPH OPTIONS: LARGER DUST COLLECTORS (2000 CFM) STAINLESS STEEL DUST COLLECTOR DIESEL POWER (30 HP) HYDRAULIC VIBRATORS BELT SCALE W/ +/-1% ACCURACY 5 FT. EXTENSION TO REACH RAILCARS USES: LOADING / UNLOADING OF SMALL PARTICLES SUCH AS: SAND SODA ASH PEBBLE LIME ROOFING GRANULES SALT click here to view a schematic drawing

MOBILE CONVEYORS - Model 3655X FEATURES: ONE MAN OPERATION TWO WHEEL DRIVE W/ FOUR WHEEL STEERING HEAD DRIVE W/ 12" TAKEUP 5" THICK LOW PROFILE TAIL FULLY ENCLOSED TROUGH 440/220V 3 PHASE POWER DUST COLLECTOR W/ AUTOMATIC SHAKER FLEXIBLE LOADOUT SPOUT W/ HAND WINCH LOCALIZED LIGHTING FOR NIGHT TIME OPERATION 2 PLY BALACK RUBBER BELT W/ VULCANIZED SEAM HEAVY DUTY BEARING CEMA B HEAVY DUTY SEALED BEARING IDLERS SHIPS LEGAL ON GOOSENECK TRAILER MODEL 3655 RATED @ 200 - 250 TONS PER HOUR OPTIONS: FOUR WHEEL DRIVE LARGER DUST COLLECTORS (2000 CFM) STAINLESS STEEL DUST COLLECTOR DIESEL POWER (30 HP) HYDRAULIC VIBRATORS BELT SCALE W/ +/-1% ACCURACY 5 FT. EXTENSION TO REACH RAILCARS USES: LOADING / UNLOADING OF SMALL PARTICLES SUCH AS: SAND SODA ASH PEBBLE LIME ROOFING GRANULES SALT click here to view a schematic drawing

MOBILE CONVEYORS - Model 4255 FEATURES: ONE MAN OPERATION TWO WHEEL DRIVE W/ FOUR WHEEL STEERING HEAD DRIVE W/ 12" TAKEUP 5" THICK LOW PROFILE TAIL ALUMINUM TROUGH COVERS 440/220V 3 PHASE POWER FLEXIBLE LOADOUT SPOUT W/ HAND WINCH LOCALIZED LIGHTING FOR NIGHT TIME OPERATION 42" VULCANIZED BLACK RUBBER BELT HEAVY DUTY BEARING CEMA B HEAVY DUTY SEALED BEARING IDLERS SHIPS LEGAL ON GOOSENECK TRAILER MODEL 4255 RATED @ 200 - 300 TONS PER HOUR (BASED ON 95# PER CUBIC FOOT OF MATERIAL) OPTIONS: FOUR WHEEL DRIVE DUST COLLECTOR W/ AUTOMATIC SHAKER STAINLESS STEEL DUST COLLECTOR DIESEL POWER (60 HP) HYDRAULIC VIBRATORS BELT SCALE W/ +/-1% ACCURACY DRIVE OVER TAIL HYDRAULICALLY DRIVEN AIR COMPRESSOR GATE OPENER REMOTE CONTROL ON/OFF USES: SAND ROCK COAL BALLAST ROCK SALT click here to view a schematic drawing

MODEL BP80 MODEL BP220 MODEL BP1400 MODEL BP2400

Boilers STANDARD FEATURES: 150 HP / 125 PSI STEAM BOILER #2 DIESEL FUEL FULL MODULATION BURNER WATER MAKE-UP TANK / STEAM PRE-HEAT ALL STATE AND LOCAL SAFETY DEVICES TWIN WATER SOFTENERS INSTALLED IN 48 FOOT SHIP CONTAINERS ALL ELECTRIC CONTROLS AUTOMATIC CHEMICAL FEEDER BLOW - DOWN SEPARATOR W/ AUTO. AFTER COOLER INTERNAL LIGHTING, HEATER, AND EXHAUST FANS DOUBLE WALL FUEL TANK PREPLUMBED AND WIRED 440 / 220 VOLT 3 PHASE POWER SHIPS LEGAL ON STEP DECK TRAILER OPTIONAL FEATURES: CUSTOM SIZE BOILERS AIR COMPRESSORS (20 - 400 CFM) AIR DRYERS -40DEG. FAHRENHEIT CUSTOM FUEL TANK SIZES STEAM LINES AIR LINES CONDENSATION RETURN LINES 20, 40 OR 50 FOOT SHIP CONTAINERS 28 OR 48 FOOT VAN TRAILERS USES: RAILCAR HEATING click here to view a schematic drawing

Blowers - Model BP1400 FEATURES: TOWABLE WAGON SELF-CLEANING FILTERS BY REVERSE PURGE AIR 99.9% FILTER EFFICIENCY @ .3 MICRONS (11) 39" TALL X 61 1/4" DIA. PLEATED FILTERS EPTFE MEMBRANE ON 100% SPUNBOND POLYESTER; 34.53 sq/ft PER FILTER = 380 sp/ft TOTAL RATED @ 1400 CFM 4506 DUROFLOW BLOWER 420CFM @ 15 PSI 40 hp 3600 RPM TEFC MOTOR OPTIONS: CUMMINS 4BT DIESEL DRIVE PACKAGE SELF PROPELLED ELEVATED PLATFORMS EXPLOSION PROOF CONTROLS 4509 DUROFLOW BLOWER 620 CFM @ 15 PSI 60hp 3600 RPM TEFC MOTOR TYPICAL SERVICE: PRESSURE DIFFERENTIAL UNLOADING OF RAILCARS OF TRUCKS. TYPICAL UNLOADING RATE OF CEMENT IS 50-60 TONS PER HOUR. USES: CEMENT FLY ASH KILN DUST BLASTING GRIT SODA ASH click here to view a schematic drawing

Blowers - Model BP220 FEATURES: SKID MOUNTED MILD STEEL CONSTRUCTION 220V / 440V 3 PHASE ELECTRIC POWER GHH RAND CS80 OIL FREE SCREW COMPRESSOR RATED AT 220CFM @ 36 PSI FURNAS STARTER / PRESSURE SWITCH DUAL CHECK VALVES ZCH DISCHARGE FILTER RATED AT 1um 30HP / 1200 RPM DIRECT DRIVE PACK OPTIONS: DIESEL POWER TOWABLE WAGON

Blowers - Model BP2400 FEATURES: TOP LOAD RAILCARS 6" LOAD LINE 1400 CFM BLOWER / 125hp DRIVE MOTOR 2400 CFM DUST COLLECTOR / 25hp DRIVE MOTOR ELEVATED PLATFORM ELETRICTY POWERED NIGHT TIME LIGHTING FALL PROTECTION 4'-0" X 4'-0" WORK PLATFORM ALUMINUM WALKWAY TO RAILCAR STAIRWAY TO PLATFORM ALL TYPES OF DRY COMMODITIES 99.9% FILTER EFFICIENCY @ .3 MICRONS (11) 39" TALL X 6 1/4" DIA. PLEATED FILTERS EPTFE MEMBRANE ON 100% SPUNBOND POLYESTER; 34.53 sp/ft. PER FILTER = 380 sp/ft. TOTAL PRESSURE DROP 2-3 PSI click here to view a schematic drawing

Blowers - Model BP80 FEATURES: TOWABLE WAGON MILD STEEL CONSTRUCTION 220V / 440V 3 PHASE ELECTRIC POWER DRUM J-100 VANE BLOWER RATED AT 80CFM @ 36 PSI FURNAS STARTER / PRESSURE SWITCH DUAL CHECK VALVES ZCH DISCHARGE FILTER RATED AT 1um 20HP / 1800 RPM DIRECT DRIVE PACK OPTIONS: DIESEL POWER SKID MOUNTED

MOBILE CONVEYORS - MODELS 1800, 2400, 3600 (3600 SHOWN) FEATURES: ONE MAN OPERATION TWO WHEEL DRIVE W/ FOUR WHEEL STEERING HEAD DRIVE W/ 12" TAKEUP 5" THICK LOW PROFILE TAIL FULLY INCLOSED TROUGH 440/220V 3 PHASE POWER DUST COLLECTOR W/ AUTOMATIC SHAKER FLEXIBLE LOADOUT SPOUT W/ HAND WINCH LOCALIZED LIGHTING FOR NIGHT TIME OPERATION SS FLATWIRE CHAIN BELT HEAVY DUTY BEARING SHIPS LEGAL ON GOOSENECK TRAILER MODEL 1800 RATED @ 45 - 55 TONS PER HOUR MODEL 2400 RATED @ 60 - 75 TONS PER HOUR MODEL 3600 RATED @ 80 - 100 TONS PER HOUR OPTIONS: LARGER DUST COLLECTORS (2000 CFM) STAINLESS STEEL DUST COLLECTOR DIESEL POWER (30 - 45 HP) HYDRAULIC VIBRATORS BELT SCALE W/ +/-1% ACCURACY DRIVE OVER TAIL 5 FT. EXTENSION TO REACH RAILCARS ALL SS CONTRUCTION USES: LOADING / UNLOADING OF SMALL PARTICLES SUCH AS: CEMENT FERTILIZER SODA ASH SALT click here to view a schematic drawing

MOBILE CONVEYORS - MODELS 2452s FEATURES: STAINLESS STEEL CONSTRUCTION ONE MAN OPERATION TWO WHEEL DRIVE W/ TWO WHEEL STEERING TAIL DRIVEN W/12" TAKEUP FULLY ENCLOSED TROUGH 440/220V 3 PHASE POWER LOCALIZED LIGHTING FOR NIGHT TIME OPERATION WHITE FOOD GRADE BELT HEAVY DUTY BEARING STAINLESS STEEL SEALED BEARING IDLERS MODEL 2452S RATED @ 50 - 80 TONS PER HOUR OPTIONS: DUST COLLECTORS DIESEL POWER (25 HP) GASOLINE POWER USES: LOADING / UNLOADING OF COCOA BEANS FROM DOCK HEIGHT OR GROUND LEVEL DESIGNED TO LOAD 48'-0" COVERED TRAILERS OR SHIP CONTAINERS HOPPER FEATURES: 12'-0" X 8'-0" HOPPER W/ CONTINUOUS BAR GRATING COVER 2'-0" X 8'-0" BOLT ON EXTENSIONS FOR EACH SIDE EASILY MOVED BY FORK LIFT 2000# CAPACITY OF COCOA BEANS REMOVABLE SAFETY HANDRAIL click here to view a schematic drawing

MOBILE CONVEYORS - MODEL 2450 SPECIAL FEATURES: STAINLESS STEEL CONSTRUCTION ONE MAN OPERATION TWO WHEEL DRIVE W/ TWO WHEEL STEERING HEAD DRIVE W/12" TAKEUP 12" THICK TAIL FULLY ENCLOSED TROUGH 440/220V 3 PHASE POWER SPECIAL LONG DISCHARGE SPOUT W/ CERAMIC LOCALIZED LIGHTING FOR NIGHT TIME OPERATION WHITE FOOD GRADE BELT HEAVY DUTY BEARING STAINLESS STEEL SEALED BEARING IDLERS MODEL 2450 RATED @ 50 - 80 TONS PER HOUR OPTIONS: DUST COLLECTORS DIESEL POWER (30 HP) GASOLINE POWER USES: LOADING / UNLOADING OF COCOA BEANS HOPPER FEATURES: 12'-0" X 8'-0" HOPPER W/ CONTINUOUS BAR GRATING COVER 2'-0" X 8'-0" BOLT ON EXTENSIONS FOR EACH SIDE EASILY MOVED BY FORK LIFT 2000# CAPACITY OF COCOA BEANS click here to view a schematic drawing

BELT 18" BELT CONVEYORS 24" BELT CONVEYORS 36" BELT CONVEYORS 42" BELT CONVEYORS CHAIN 18" CHAIN CONVEYORS 36" CHAIN CONVEYORS 36" CHAIN CONVEYORS COCOA BEAN COCOA BEAN I COCOA BEAN II DRAG-A-FLIGHT< MODEL 3625

Dust Collectors - Model DC1400 FEATURES: TOWABLE CART SELF-CLEANING FILTERS BY REVERSE PURGE AIR NON ELECTRIC 99.9% EFFICIENCY @ .3 MICRONS (11) 39" TALL X 6 1/4" DIA. PLEATED FILTERS EPTFE MEMBRANE ON 100% SPUNBOND POLYESTER; 34.53 sq./ft PER FILTER = 380 sq/ft TOTAL RATED @ 1400 CFM PRESSURE DROP 2-3 PSI RENTAL UNITS AVAILABLE OPTIONS: CUSTOM DESIGNED ELECTRIC OR DIESEL BLOWERS CAN BE MOUNTED ON UNIT FALSE DOMELIDS FOR RAILCAR OR TRUCKS USES: ANY DUST COMMODITY THAT REQUIRES PNEUMATIC CONVEYING AND DUST RECOVERY SUCH AS: CEMENT FLY ASH KILN DUST BLASTING GRIT SODA ASH click here to view a schematic drawing

Dust Collectors - Model DC2000X FEATURES: ELEVATED PLATFORM W/ ALUMINUM WING MILD STEEL CONTRUCTION DUST COLLECTOR W/ 325 SQ. FT. CLOTH AREA 2000 CFM - 7 1/2 HP DUST RECOVERY BLOWER 5HP TWO-STAGE AIR COMPRESSOR 4" MANIFOLD PIPING TOWABLE 8-TON WAGON ASSEMBLY ELECTRICAL CONTROLS & 125 FT. POWER CORD 480V 3 PHASE POWER LIGHTING FOR NIGHT TIME USE GROUNDING STRAPS WHEEL CHOCKS ALUMINUM STORAGE BOXES OPTIONS: FALL PROTECTION HIGHER CFM DUST COLLECTION DIESEL POWER DUAL ALUMINUM WINGS DUAL HOSE RACKS USES: UNLOAD DUST COMMODITIES FROM PNEUMATIC TRAILERS TO RAILCARS click here to view a schematic drawing

Dust Collectors - Model DC600 FEATURES: 50 HP TEFC DRIVE 4509 BLOWER 400 CFM @ 15 PSI OR 15" VACUUM REVERSING STARTER 100 FT. POWER CORD LIFTING CORD 3 CU. FT. COLLECTION HOPPER AUTOMATIC LEVEL INDICATOR "SHUTS OFF VACUUM" UNIT WEIGHT - 4500# UNIT WEIGHT WITH TRAILER - 5200# OPTIONALS: TOWABLE FARM STYLE DIESEL POWERED LARGER COLLECTION HOPPER USES: VACUUM AND RECLAIM SAND BLAST ABRASIVE FROM SHIP HULLS

MOBILE CONVEYORS - MODEL 3625 FEATURES: ONE MAN OPERATION 36" DRAG-A-FLIGHT W/UHMW PADDLES AR400 DRAG FLOOR HEAD DRIVE W/7" TAKEUP FULLY ENCLOSED TROUGH 440/220V 3 PHASE POWER 600 CFM DUST COLLECTOR W/ AUTOMATIC SHAKER FLEXIBLE LOADOUT SPOUT W/ HAND WINCH LOCALIZED LIGHTING FOR NIGHT TIME OPERATION DUAL HEAVY DUTY CHAIN HEAVY DUTY BEARING SHIPS LEGAL ON GOOSENECK TRAILER MODEL 3625 RATED @ 80 - 100 TONS PER HOUR (BASED ON 80# PER CUBIC FOOT OF MATERIAL) FOUR WHEEL DRIVE W/ FOUR WHEEL STEERING OPTIONS: LARGER DUST COLLECTORS (2000 CFM) STAINLESS STEEL DUST COLLECTOR DIESEL POWER (60 HP) NON-IMPACT VIBRATORS HYDRAULIC OR AIR VIBRATOR IMPACT SCALE W/ +/-1% ACCURACY HYDRAULICALLY DRIVEN AIR COMPRESSOR AIR OPERATED GATE OPENER USES: FLYASH CEMENT LIMESTONES OTHER FLOWABLE COMMODITIES click here to view a schematic drawing

Heating Systems - Custom Boilers, For Steam or Hot Water STANDARD FEATURES: 150 HP / 125 PSI STEAM BOILER 2 DIESEL FUEL FULL MODULATION BURNER WATER MAKE-UP TANK / STEAM PRE-HEAT ALL STATE AND LOCAL SAFETY DEVICES INSTALLED IN 40'-0" SHIP CONTAINER BLOW - DOWN SEPARATOR W/ AUTOMATIC AFTER COOLER DOUBLE WALL FUEL TANK 440 / 220 VOLT 3-PHASE POWER USES: RAILCAR HEATING Heating Systems - Steam to Hot Water Heater, Model HW400 FEATURES: 400 GALLON WATER TANK. STEAM CONTROL VALVE 105° - 195°. SIGHT GUAGE AND THERMOMETER 10,000 WATT, 480 VOLT HEATER/THERMOSTAT AND CONTROLS FOR NIGHT-TIME STORAGE 8 TON TOW ABLE WAGON CIRCULATION PUMPS HOSE RACKS USES: FOR HEATING TEMPERATURE SENSITVE LIQUIDS WHEN ONLY STEAM IS AVAILABLE STAINLESS STEEL OPTION CAN BE USED TO WASH OUT FOOD GRADE PUMPS   Steam to Hot Water Heater, Model HW400 PORTABLE PLATFORMS - MODEL AP500 FEATURES: TOWABLE HEAVY DUTY WAGON ELEVATED PLATFORM 4'-0" X 6'-8" STAIRWAY TO PLATFORM ALUMINUM WALKWAY 100 GPM ANSI MAG PUMP 15 PSI BLOWER PACKAGE DUAL STATION ALL WEATHER SAFETY SHOWER AND EYEWASH COMPLETE DUAL TANK SCRUBBER SYSTEM (HYDROCHLORIC ACID EMISSION RATE <.0001 LB/HR AFTER BEING SCRUBBED WITH WATER) PRODUCT METER W/ DUAL READOUTS AT TOP & BOTTOM OF UNIT HASTALLOY PUMP SHUT-OFF PROBE TO AVOID OVER FILLING MEETS AND OR EXCEEDS ALL APPLICABLE OSHA REQUIREMENTS AS WE INTERPRET THEM OPTIONS: SELF-PROPELLED AIR CONDITIONED & HEAT CAB USES: FOR TOP UNLOADING OF HYDROCHLORIC AND SULFURIC ACIDS TO TRUCKS click here to view a schematic drawing PORTABLE PLATFORMS - MODEL AV200 FEATURES: TOWABLE HEAVY DUTY WAGON ELEVATED PLATFORM 4'-0" X 6'-8" STAIRWAY TO PLATFORM ALUMINUM WALKWAY 200 GPM CORKEN VANE PUMP LETRO COUNT LIQUID CONTROL METER W/ REMOTE TICKET PRINTOUT DUAL STATION ALL WEATHER SAFETY SHOWER AND EYEWASH WATER SEPARATOR / FILTER 200 GALLON SLOP TANK FOR SAMPLES SCULLY GROUND VERIFICATION / TRUCK OVERFILL PROTECTION VAPOR RECOVERY SYSTEM MEETS AND OR EXCEEDS ALL APPLICABLE OSHA REQUIREMENTS AS WE INTERPRET THEM OPTIONS: SELF-PROPELLED AIR CONDITIONED & HEAT CAB USES: FOR TOP UNLOADING OF AVIATION FUELS FROM RAILCAR TO TRUCK click here to view a schematic drawing PORTABLE PLATFORMS - MODEL PP106 FEATURES: TOP LOAD RAILCARS 6" LOAD LINE ALL TYPES OF COMMODITIES (RECYCLED OIL & SLUDGE SHOWN HERE) 5'-0" X 5'-0" FOOT WORK PLATFORM ALUMINUM WALKWAYS STAIRWAY TO PLATFORM RENTAL UNITS AVAILABLE MEETS AND OR EXCEEDS ALL APPLICABLE OSHA REQUIREMENTS AS WE INTERPRET THEM FALL PROTECTION OPTIONS: DIESEL POWERED SELF-PROPELLED SAFETY SHOWERS FUME SCRUBBERS FULLY ENCLOSED OPERATORS PLATFORM ALL TYPES OF FILTRATION VARIOUS PUMP & COMPRESSOR CONFIGURATIONS click here to view a schematic drawing PORTABLE PLATFORMS - MODEL SP320 FEATURES: TOP LOAD RAILCARS / TOP LOAD TANK TRUCKS 200 GPM LIQUID CONTROL METER 1/2% ACCURACY ALL TYPES OF COMMODITIES (FLAMMABLE SOLVENTS SHOWN HERE) 5'-0" X 5'-0" FOOT WORK PLATFORM ALUMINUM WALKWAYS STAIRWAY TO PLATFORM RENTAL UNITS AVAILABLE MEETS AND OR EXCEEDS ALL APPLICABLE OSHA REQUIREMENTS AS WE INTERPRET THEM OPTIONS: DIESEL POWERED SELF-PROPELLED SAFETY SHOWERS FUME SCRUBBERS FULLY ENCLOSED OPERATORS PLATFORM ALL TYPES OF FILTRATION VARIOUS PUMP & COMPRESSOR CONFIGURATIONS USES: TO TRANSFER LIQUID COMMODITIES FROM TOP OF RAILCAR TO TOP OF TRUCK click here to view a schematic drawing BOOT SEAL - MODEL 1324 FEATURES: STAINLESS STEEL CONSTRUCTION SEALED BEARING PIVOTS SMOOTH HYDRAULIC CONTROLS 110V AC CONTROLS (20 AMP) LOCKABLE OPERATOR CONTROL CONSOLE HYDRAULIC ACCUMULATOR (AUTOMATICALLY RAISES AS RAILCAR RISES) DUAL 13" X 24" INLETS W/ TWIN SPREAD CYLINDERS TO ADJUST TO DIFFERENT RAILCAR GATES ROUND PRODUCT HOSE FOR EASY HOOK-UP OPTIONS: VARIOUS ADAPTER PLATES & GASKET CONFIGURATIONS VARIOUS GASKET MATERIALS USES: SEAL BETWEEN RAILCARS AND UNDERTRACK CONVEYORS click here to view a schematic drawing RAILROAD ACCESSORIES - AUTOMATIC STEAM CONTROL FEATURES: DIGITAL TEMPERATURE READOUT DUAL READOUTS: ACTUAL TEMPERATURE AND SET POINT ACCURACY +/- 1% NEMA 3 ENCLOSURE TIMER FUNCTION UL/FM/CSA APPROVED 110 VOLT AC STAINLESS STEEL TEMPERATURE PROBE, 36" STANDARD LENGTH IN THE EVENT OF A POWER FAILURE THE VALVE WILL AUTOMATICALLY CLOSE ELIMINATE UNNECESSARY LABOR BUMPER POST - MODEL 1010 FEATURES: HEAVY DUTY, ALL STEEL CONSTRUCTION DESIGNED TO TRANSFER IMPACT FROM CAR COUPLER TO TRACK AND GROUND EASY INSTALLATION, WILL INSTALL ON EXISTING RAILS ALL HARDWARE INCLUDED CAR PULLERS - MODEL CP1590 FEATURES: 15,000# STARTING PULL 9,000# RUNNING PULL 200 FT. ROPE & HOOK 15 FPM NEMA 4 CONTROLS 220/440 VOLT 3 PHASE POWER 5HP TEFC MOTOR IN STOCK READY FOR INSTALLATION OPTIONAL EQUIPMENT: REVERSING SHEAVE SAFETY FENCE LONGER ROPES CAR PULLERS - MODEL CP2034 FEATURES: 1" DIA. IWRC NEMA 4 CONTROLS W/ FORWARD & REVERSING STARTER 15 HP TEFC MOTOR/BRAKE JAW CLUTCH TO ALLOW MANUAL PAYOUT OF CABLE DELIVERY 3-4 WEEKS 220V / 440V THREE PHASE POWER OPTIONAL EQUIPMENT: REVERSING SHEAVE SAFETY FENCE LONGER WIRE ROPES VERTICAL GUIDE ROLLERS LAYERS STORAGE FULL WRAP SPEED RUNNING PULL STARTING PULL #1 97 ft. 22 fpm 22,000 # 33,000 # #2 107 ft. 25 fpm 19,000 # 29,000 # #3 119 ft. 28 fpm 17,000 # 26,000 # #4 131 ft. 31 fpm 16,000 # 24,000 # #5 143 ft. 34 fpm 14,000 # 22,000 # #6 154 ft. 36 fpm 13,000 # 20,000 # #7 166 ft. 39 fpm 12,000 # 18,000 #   917 ft=TOTAL WRAP     CROSS DOCK FEATURES: 20 TON TRAILER CHASSIS DUAL STABILIZING OUTRIGGERS (3) 9'-0" TALL X 8'-0" WIDE ROLL UP DOORS (REAR DOOR - 9'-0" WIDE X 7'-7" TALL) (SIDE DOORS - 9'-0" WIDE X 7'-9" TALL) VINYL FOLD OUT AWNING (2) 4'-0" X 9'-6" SKYLIGHTS INTERIOR GUARD RAIL BOLLARDS TO PROTECT DOORS 8'-10" HT X 9'-9" WIDE X 34'-4" LG INTERIOR 13'-6" HT X 11'-0" WIDE X 34'-8" LG EXTERIOR APITONG - KERUING WOOD FLOORING ALUMINUM SIDING OPTIONS: PORTABLE FORKLIFT ACCESS RAMP ALUMINUM DOCK PLATES TO ACCESS BOXCAR OR VAN TRAILER USES: PORTABLE PLATFORM TO ALLOW TRANSFER OF DRY GOODS FROM BOXCAR TO VANTRAILER VIA FORKLIFT click here to view a schematic drawing FIFTH WHEEL DUMP CHASSIS FEATURES: TWIN CYLINDER HOIST LIFT CAPACITY OF APPROXIMATELY 40 TONS HEAVY DUTY LEAF SPRING SUSPENSION ELEVATE 40' TRAILERS UP TO 30 DEGREES ELEVATE 60' TRAILERS UP TO 60 DEGREES RECOMMENDED FOR TRAILERS UP TO 45' LONG SHOWN ON 1992 MACK TRUCK FRAME OPTIONS: OUTRIGGERS FOR USE ON UNEVEN SURFACES USES: DUMP BOX VANS OR SHIP CONTAINERS UNITS AVAILABLE FOR PURCHASE OR RENTAL click here to view a schematic drawing GATE OPENERS - VARIOUS MODELS MODEL M30 FEATURES: UNIT WEIGHT 40# 3000 FT. LB OF TORQUE REMOVABLE SPUD BAR INCLUDED SQUARE DRIVE ADAPTS TO DIFFERENT RAILCAR GATES SINGLE DIRECTION ROTATION MODEL 40 FEATURES: UNIT WEIGHT 120# 1500 FT LB OF TORQUE SQUARE DRIVE ADAPTS TO DIFFERENT RAILCAR GATES ELECTRIC OPENER FEATURES: UNIT WEIGHT 300# 1400 FT LB OF TORQUE SQUARE DRIVE ADAPTS TO DIFFERENT RAILCAR GATES AIR OPENER FEATURES: UNIT WEIGHT 77# 70 CFM @ 80-125 PSI TO PRODUCE 1750 FT. LB. OF TORQUE SQUARE DRIVE ADAPTS TO DIFFERENT RAILCAR GATES MODEL M30 MODEL 40 ELECTRIC OPENER AIR OPENER HOT WATER HEATER - MODEL HW400 FEATURES: 400 GALLON WATER TANK 8 TON TOWABLE WAGON STEAM CONTROL VALVE 105-195 DEG. CIRCULATION PUMPS SIGHT GUAGE AND THERMOMETER 10,000 WATT, 480 VOLT HEATER/THERMOSTAT AND CONTROLS FOR NIGHT-TIME STORAGE HOSE RACKS OPTIONS: LARGER CAPACITY DIESEL POWERED STAINLESS STEEL CONSTURCTION FOR WASHING OUT FOOD GRADE PUMPS USES: FOR HEATING TEMPERATURES SENSITIVE LIQUIDS WHEN ONLY STEAM IS AVAILABLE STAINLESS STEEL OPTION CAN BE USED TO WASH OUT FOOD GRADE PUMPS TRACK PANS FEATURES: ALUMINUM, MILD STEEL OR STAINLESS STEEL HOLDS 150 GALLONS PER 10 FT SECTION EASY INSTALLATION, ALL HARDWARE INCLUDED ONE 1" DIA DRAIN EVERY 10 FT SPECIAL APPLICATIONS AVAILABLE click here to view a schematic drawing TEMPERATURE PROBE FEATURES: DIGITAL TEMPERATURE READOUT BATTERY POWERED STAINLESS STEEL TEMPERATURE PROBE WATERPROOF CONSTRUCTION FIELD CALIBRATABLE TEMPERATURE RANGE OF 100° - 999° F (-73° - 537° C) AUTOMATIC SHUT-OFF MOVE FROM RAILCAR TO RAILCAR INCLUDES MOUNTING BRACKET USES: TO CHECK TEMPERATURE LEVELS OF RAILCARS AT THREE DIFFERENT LEVELS: BOTTOM, MIDDLE, & TOP SAFETY SHOWERS - MODEL SS10 FEATURES: CONNECTS TO USER WATER SUPPLY EYEWASH HEIGHT - 40” OFF FLOOR SAFETY SHOWER HEIGHT - 83” OFF FLOOR BOTH EYEWASH & SHOWER START WITHIN 1 SECOND HIGHLY VISIBLE SIGNAGE OPTIONS: EXPLOSION PROOF CONTROLS click here to view a schematic drawing SAFETY SHOWERS - MODEL SS125 FEATURES: 125 GALLON HEATED WATER TANK HEAVY DUTY TOWABLE RUNNING GEAR INSULATED CABINET 480V/240V 3 PHASE, 110V 1 PHASE POWER BEACON LIGHT TO INDICATE THAT UNIT IS READY FOR USE EYEWASH - .4 GPM / 15 MINUTE FLUSH SAFETY SHOWER - 15 GPM/7 MINUTE WASH USES: EXPLOSION PROOF CONTROLS click here to view a schematic drawing NEW PORTABLE SAFETY SHOWER - MODEL SS300 FEATURES: 350 GALLON HEATED TANK (ADJUSTABLE FROM 78 - 92 DEG. F.) 6 TON HEAVY DUTY TOWABLE RUNNING GEAR INSULATED HOUSING 480V / 240V 3 PHASE POWER EYEWASH - .4 GPM / 15 MINUTE FLUSH EYEWASH HEIGHT - 44” OFF FLOOR SAFETY SHOWER - 20 GPM / 17.5 MINUTE WASH SAFETY SHOWER HEIGHT - 89” OFF FLOOR BOTH EYEWASH & SHOWER START WITHIN 1 SECOND HIGHLY VISIBLE SIGNAGE MEETS REQUIRED ANSI Z358.1-1998 SPEC RENTAL UNITS AVAILABLE OPTIONS: EXPLOSION PROOF CONTROLS click here to view a schematic drawing HOSE STORAGE RACK FEATURES: LOCKABLE STORAGE 25 INDIVIDUAL COMPARTMENTS 6" DIAMETER AND SMALLER HOSES UP TO 20 FEET LENGHTS KEEPS AREA CLEAN LABEL FOR DIFFERENT COMMODITIES click here to view a schematic drawing FILL TUBES FEATURES: TOWABLE 5 TON WAGON MILD STEEL LOADING ARM ALUMINUM CAM LOCK INLET ALUMINUM CAM LOCK OUTLET 7'-0" DISCHARGE HOSE PRODUCT VALVE ON BOTTOM INLET WHEEL CHOCKS ALUMINUM TOOL BOX OPTIONS: VARIOUS LOAD TUBE SIZES VARIOUS SPLASH GUARD SIZES GROUND STRAPS PUMPS METERS USES: TOP LOADING OF LIQUIDS INTO RAILCARS STATIONARY CHAIN CONVEYORS FEATURES: HEAVY DUTY STAINLESS STEEL FLAT-WIRE CHAIN FULLY ENCLOSED, MILD STEEL TROUGHS CUSTOM BUILT TO LENGTH DIRECT COUPLED SHAFT MOUNT GEAR BOX TAPERED ROLLER BEARINGS 7" ADJUSTABLE TAKEUP ASSEMBLY MANUAL BOOT LIFT ALL UNDERGROUND SECTIONS CONSTRUCTED WATER TIGHT OPTIONS: DUST COLLECTOR W/ AUTOMATIC SHAKER COMPLETE ELECTRIC CONTROLS MODEL 1324 HYDRUALIC BOOT SEAL AIR COMPRESSORS CAR PULLERS VIBRATORS STAINLESS STEEL CONSTRUCTION USES: CEMENT, SODA ASH, FERTILIZER AND OTHER FLOWABLE MATERIALS STATIONARY CHAIN CONVEYORS STATIONARY DRAG-A-FLIGHT CONVEYORS STATIONARY INGROUND DRAG - A - FLIGHT CONVEYORS FEATURES: CONSTRUCTED OF ABRASION RESISTANT PLATE HEAVY DUTY CHAIN 12" TAKE-UP IN TAIL SECTION HEAVY DUTY ROLLER BEARINGS TEFC ELECTRIC MOTORS LOADOUT SPOUT W/ FOAM GASKET ALL UNDERGROUND SECTIONS CONSTRUCTED WATER TIGHT OPTIONS: DUST COLLECTOR W/ AUTOMATIC SHAKER COMPLETE ELECTRIC CONTROLS MODEL 1324 HYDRUALIC BOOT SEAL AIR COMPRESSORS CAR PULLERS VIBRATORS STAINLESS STEEL CONSTRUCTION USES: LIME, CEMENT, FLYASH & OTHER COMMODITIES BAUXITE UNLOADING FACILITY TRUSS CONVEYORS: 6 FOOT TRUSS DEPTHS 55" & 84" BELT WIDTHS HEAVY DUTY SUPPORTS CEMA C SEALED BEARING IDLERS SHAFT MOUNT GEAR BOX DRIVES BELT WIPERS W/ REPLACEMENT BLADES LIGHTED CATWALK ON BOTH SIDES OR CONVEYOR CUSTOM DESIGNED ABRASION RESISTANT DISCHARGE CHUTE DUAL HYDRAULIC LIFT CYLINDERS HEAVY DUTY HOPPERS OPTIONS: LARGER CAPACITIES COMPLETE DUST COLLECTION SYSTEMS CAR PULLERS VIBRATORS CEMENT TRANSFER TERMINAL SCREW CONVEYORS: 20" DIAMETER SCREW CONVEYOR RAIL UNLOADING RATE - 200 TPH SHAFT MOUNTED GEAR BOX DRIVES PNUEMATICALLY CONTROLLED RAILCAR SEAL BUCKET ELEVATOR: 22" X 55" X 96'-0" ELEVATOR CHAIN STYLE W/ CAST IRON DRIVES RATED @ 200 TPH HEAVY DUTY BEARINGS SHAFT MOUNTED GEAR BOX DRIVES GRAVITY TAKE-UP SILOS: (2) 200 TON SILOS (2) 300 TON SILOS ALL WELDED CONSTRUCTION DUST CONSTRUCTION KNIFE GATES, SPOUTING & SPLITTERS UNLOAD RATE - 300TPH MISC: 20 HP AIR COMPRESSOR REINFORCED CONCRETE FOUNDATIONS ALL ELECTRICAL CONTROLS & FIELD WIRING FIELD ERECTION & START-UP IRON ORE BARGE UNLOADING FACILITY TRUSS CONVEYORS: 5 AND 6 FOOT TRUSS DEPTHS FREE SPANS OF UP TO 102 FEET HEAVY DUTY SUPPORTS GRAVITY TAKE-UPS CEMA C IDLERS SHAFT MOUNT GEAR BOX DRIVES CERTIFIABLE BELT SCALE 180 DEGREE COVERS & CATCH PAN LIGHTED CATWALK CUSTOM DESIGNED "Z" & "L" CONVEYORS: 5 FOOT TRUSS DEPTH PADDLE STYLE BELT W/ 6" SIDEWALLS & CLEATES CEMA C IDLERS 180 DEGREE COVERS & CATHC PAN LIGHTED CATWALK CUSTOM DESIGNED RIVER HOPPER: HEAVY DUTY AR400 PLATE CONSTRUCTION 8" X 8" DUMP GRATING VIBRATING FEEDER OPTIONS: DUST BAFFLES ON RIVER HOPPERS COMPLETE DUST COLLECTION SYSTEMS INGROUND PADDLE BELT CONVEYOR CONVEYORS: HEAVY DUTY REX PILLOW BLOCK BEARINGS DCE UMA152 DUST COLLECTION SYSTEM MIDWEST LOADOUT SPOUT W/ 8'-0" VERITCAL TRAVEL 36" CAMWALL BELT W/3" SIDEWALL & 6" CLEAT SPACING SHAFT MOUNT GEAR BOX DRIVES ALUMINUM COVERS CUSTOM DESIGNED OPTIONS: LARGER LOAD-OUT SPOUTS LARGER DUST COLLECTION SYSTEM ROOFING GRANULES UNLOADING FACILITY TRUSS CONVEYORS: 3 FOOT TRUSS DEPTHS 36" SMOOTH TOP BELT HEAVY DUTY SUPPORTS GRAVITY TAKE-UPS CEMA C SEALED BEARING IDLERS SHAFT MOUNT GEAR BOX DRIVES 180 DEGREE GALVANIZED STEEL COVERS ROTARY BRUSH CLEANER LIGHTED CATWALK ON BOTH SIDES OR CONVEYOR CUSTOM DESIGNED ABRASION RESISTANT DISCHARGE CHUTE W/ 11" DIA. FLEXIBLE DISCHARGE SPOUTS ABRASION RESISTANT PNUEMATICALLY CONTROLLED SPLITTER OPTIONS: LARGER CAPACITIES COMPLETE DUST COLLECTION SYSTEMS CAR PULLERS INGROUND PADDLE BELT CONVEYOR IRON ORE BARGE UNLOADING FACILITY ROOFING GRANULES UNLOADING FACILITY BAUXITE UNLOADING FACILITY CEMENT TRANSFER TERMINAL BULK STORAGE & DISTRIBUTION FACILITY SCREENING & BLENDING FACILITY ZC FILTER - ZC FILTER Our new, in-line, high-volume filtration unit for pneumatic conveying systems is now available for pneumatic trailer and tractors that transport contaminant sensitive products. Marketed under the name ZC FILTER, this assembly is also designed specifically for both mobile and stationary units used in and around plant operations. “ZC” means zero contamination. FEATURES: 11 GUAGE ALUMINUM CONSTRUCTION FOR GREATED DURABILITY 4" DIA. SCH 40 INLET AND OUTLET PIPING WITH TWIN 1/4" TAPS FOR MONITORING PRESSURE ON EITHER SIDE OF FILTER EASY, QUICK RELEASE CLAMPING OF END-CAP FOR ELEMENT REMOVAL AND QUALITY INSPECTION TOTAL WEIGHT OF 22LBS WITH STAINLESS STEEL MOUNTING BRACKETS PRESSURE RATING OF 75PSI REPLACEMENT AND FULLY CLEANABLE FILTER ELEMENT FEATURING FILTER SPECIFICATIONS: FDA APPROVED MEDIUM WITH 99% MAXIMUM EFFICIENCY FOR REMOVING ALL PARTICLES AT (1) ONE MICRON AND LARGER WILL CAPTURE 100% OF HOT OIL OR OIL MIST FROM BEARING AND/OR BLOWER FAILURE WILL HANDLE AIR VOLUMES AT 1000 CFM WITH .05 PSI BACK PRESSURE MAXIMUM TEMPERATURE 400 DEG. F 304SS BODY WITH 22 SQ FT OF MEDIUM AND 90 PLEATS OPTIONS: 2" INLET & OUTLET (MODEL ZCII) click here to view a schematic drawing ZC FILTER - ZCII FILTER Our new, in-line, high-volume filtration unit for pneumatic conveying systems is now available for pneumatic trailer and tractors that transport contaminant sensitive products. Marketed under the name ZC FILTER, this assembly is also designed specifically for both mobile and stationary units used in and around plant operations. “ZC” means zero contamination. FEATURES: 11 GUAGE ALUMINUM CONSTRUCTION FOR GREATED DURABILITY 2" DIA. SCH 40 INLET AND OUTLET PIPING WITH TWIN 1/4" TAPS FOR MONITORING PRESSURE ON EITHER SIDE OF FILTER EASY, QUICK RELEASE CLAMPING OF END-CAP FOR ELEMENT REMOVAL AND QUALITY INSPECTION TOTAL WEIGHT OF 22LBS WITH STAINLESS STEEL MOUNTING BRACKETS PRESSURE RATING OF 75PSI REPLACEMENT AND FULLY CLEANABLE FILTER ELEMENT FEATURING FILTER SPECIFICATIONS: FDA APPROVED MEDIUM WITH 99% MAXIMUM EFFICIENCY FOR REMOVING ALL PARTICLES AT (1) ONE MICRON AND LARGER WILL CAPTURE 100% OF HOT OIL OR OIL MIST FROM BEARING AND/OR BLOWER FAILURE WILL HANDLE AIR VOLUMES AT 1000 CFM WITH .05 PSI BACK PRESSURE MAXIMUM TEMPERATURE 400 DEG. F 304SS BODY WITH 22 SQ FT OF MEDIUM AND 90 PLEATS click here to view a schematic drawing ZC FILTER - ZC FILTER W/ HINGED LID Our new, in-line, high-volume filtration unit for pneumatic conveying systems is now available for pneumatic trailer and tractors that transport contaminant sensitive products. Marketed under the name ZC FILTER, this assembly is also designed specifically for both mobile and stationary units used in and around plant operations. ZC means zero contamination. FEATURES: 11 GUAGE ALUMINUM CONSTRUCTION FOR GREATED DURABILITY 4" DIA. SCH 40 INLET AND OUTLET PIPING WITH TWIN 1/4" TAPS FOR MONITORING PRESSURE ON EITHER SIDE OF FILTER EASY, QUICK RELEASE CLAMPING OF END-CAP FOR ELEMENT REMOVAL AND QUALITY INSPECTION TOTAL WEIGHT OF 29LBS WITH STAINLESS STEEL MOUNTING BRACKETS PRESSURE RATING OF 75PSI REPLACEMENT AND FULLY CLEANABLE FILTER ELEMENT FEATURING FILTER SPECIFICATIONS: FDA APPROVED MEDIUM WITH 99% MAXIMUM EFFICIENCY FOR REMOVING ALL PARTICLES AT (1) ONE MICRON AND LARGER WILL CAPTURE 100% OF HOT OIL OR OIL MIST FROM BEARING AND/OR BLOWER FAILURE WILL HANDLE AIR VOLUMES AT 1000 CFM WITH .05 PSI BACK PRESSURE MAXIMUM TEMPERATURE 400 DEG. F 304SS BODY WITH 22 SQ FT OF MEDIUM AND 90 PLEATS click here to view a schematic drawing
